| Form Factor | ATX |
| Chassis Color | Black / White |
| Dimensions (WxDxH) | 16.96" x 16.26" x 6.93" / 431mm x 413mm x 176mm |
| Chassis System Fan | 2x 80mm Cooling Fan with Replaceable Fan Filter |
| Chassis Construction | Heavy Duty Metal |
| CPU | Intel® 4th Gen Core™ i |
| Chipset | Intel® H81 |
| Memory | 4GB DDR3 1600MHz SDRAM Memory |
| Max Memory | 16GB DDR3 |
| Hard Drive | 2x 3.5" SATA 6Gb/s Hard Drive Bay |
| USB 3.0 Port | 2x USB3.0 |
| USB 2.0 Port | 2x USB2.0 |
| Gigabit LAN Port | 2x Gigabit LAN Port (RJ-45) |
| RS232 COM Port | 2x RS232 (DB9) |
| RS422/485 COM Port | 1x RS422/485 (DB9) (Optional) |
| Display | 1x DVI-D, 1x VGA |
| Audio | 1x Line-Out, 1x Line-In, 1x Mic-In |
| Expansions | 1x PCIe x16
2x PCIe x1
4x PCI |
| Watchdog Timer | 1~255 sec. Software Programmable |
| Operating Temperature | 32°F ~ 140°F (0°C ~ 60°C) |
| Weight (Net/Gross) | 30 lbs / 40 lbs (13.4 Kg / 18 Kg) |
